46 SMG digital gateway
ALARM LED turns on and the alarm is registered in the alarm log).
Line code —the method of channel information encoding (HDB3, AMI).
Slip indication—when checked, any slips identified in the reception path result is fault indication.
Slip detection timeout—time interval for stream parameters polling on the card; if a slip is
detected in the stream, the gateway will indicate an alarm during the timeout.
4.1.5.3 Q.931 Signalling Protocol Configuration
Physical Parameters/Q.931 Tab
