Scalding/burns
Hot furnace / combustion tube / analyzer parts
− Parts of the analyzer can be very hot.
• Use heat protecting gloves.
1. Turn both screws (1) counter clockwise, until the ring (3) touches the
part (2).
2. Lift the glass tube (5) upwards, tilt it to the side and pull downwards.
3. Replace the magnesium perchlorate (Anhydrone). See chapter
reagent tube replacing
4. Install the glass tube (5) in reverse order after greasing the lower O-
ring.
5. Turn both screws (1) clockwise until the O-ring (4) is properly pressed
on the inner surface of the glass tube (5).
Remark
The O-ring imprint on the whole circle length of the glass tube should be of about 2 mm width.
