6 Picture change
The dots below the picture indicate the number and position of available pictures. Slide left or
right through the picture for change to the next / previous picture.
7 Coupling screen
Touch the coupling symbol for open the coupling screen. The screen offers all options for change
the coupling. See to the phenomenon description for more information.
Set and test window
The screen for each phenomenon separated in two different screens. The figure below illustrates the state
machine during the testing.
SET screen: Screen for setting all test parameters (yellow circle).
TEST screen: Screen during a test is running. After the START the user can PAUSE and START (Resume) or
STOP the test (grey circle)
Testing: Test is running
Break: Test is paused and can be continued with start
Resume: Test is running and continued after a break
Stop: Test is stopped during running or at a break. The test is not completed with all test
sequences. A stopped test cannot be continued.
Finished: The test is completed and terminated with all test sequences
