EMC Celerra User Manual

server_vtlu
495
The server Commands
Where:
EXAMPLE #13 To list VTLU information on VTLU 3, type:
$ server_vtlu server_2 -tape -list 3
server_2 :
barcode filesystem capacity(GB) location source_slot
dstpre0001 ufs1 1 vault
dstpre0002 ufs1 1 vault
dstpre0003 ufs1 1 vault
dstpre0004 ufs1 1 vault
dstpre0005 ufs1 1 vault
dstpre0006 ufs1 1 vault
dstpre0000 ufs1 1 impexp:0
Where:
EXAMPLE #14 To insert the specified tape in a virtual import/export slot on VTLU
3, type:
$ server_vtlu server_2 -tape -insert dstpre0001 -tlu 3
server_2 : done
EXAMPLE #15 To eject the specified tape from VTLU 3, type:
$ server_vtlu server_2 -tape -eject dstpre0001 -tlu 3
server_2 : done
EXAMPLE #16 To list the storage drive on VTLU 3, type:
$ server_vtlu server_2 -drive -list 3
server_2 :
drive_id device_name serial_number status tape_barcode
0 c1t0l1 NXB2w4W000 empty
1 c1t0l2 3u0bx4W000 empty
2 c1t0l3 g0pgy4W000 empty
Where:
Value Definition
tlu_id unique VTLU identifier that is assigned automatically.
filesystem name of the file system associated with the VTLU.
barcode_prefix modifiable prefix assigned to virtual tapes that is constant across a file system.
Value Definition
barcode virtual tape barcode, consisting of the modifiable barcode prefix and a four-digit number that is assigned
automatically.
filesystem name of the file system.
capacity (GB)virtual tape capacity in GB.
location element type and element ID of the virtual tape; possible element types are slot, drive, import/export, robot, and
vault.
source_slot slot ID of the tape’s previous location.
Value Definition
drive_id unique VTLU drive identifier that is assigned automatically.
device_name the device name of the VTLU drive.
