2-4
EMC Connectrix B Series DS-4900B Hardware Reference Manual
Installing and Configuring the DS-4900B
Items included with the DS-4900B
The following items are included with the DS-4900B:
◆ The DS-4900B switch, containing three fan assemblies and two
power supplies
◆ 32 SFP (small-form-factor pluggable) transceivers (64 total
optional)
◆ One accessory kit, containing the following items:
• Fabric Manager Evaluation CD (not required for installation).
• Rubber mounting feet (to be used when setting up the
DS-4900B as a standalone unit).
• Two grounded 6-ft (approximately 1.83 m) country-specific
power cords.
• One RJ-45 serial cable cable, 10-ft (approximately 3 m) long.
The DS-4900B uses an RJ-45 connector for the serial port. An
RJ-45 to DB9 adaptor is also provided with the switch.
