4-2
EMC Connectrix B Series DS-4900B Hardware Reference Manual
Fan Assembly Replacement Procedure
Fan assembly replacement
Fan assembly replacement should be performed by an EMC
Customer Service Representative.
Note: Customer servicing of the DS-4900B could result in the voiding of the
warranty or service agreement.
The DS-4900B switch has three fan assemblies as displayed in
Figure 4-1. The Fabric OS identifies the fans from left to right as Fan
assembly #3, Fan assembly #2, and Fan assembly #1.
Figure 4-1 DS-4900B fan assemblies on the nonport side
Scale: 1/8" = 1"
ATT EN
TI
ON
:
Ma
x
i
m
um s
c
r
e
w
le
n
gt
h
f
o
rra
ck
mo
un
t
ing
t
obe5mm
o
r13
/
6
4
i
n
.
Scale:
5/16" = 1"
2
1
543
