Initial setup of the DS-4900B
2-11
Installing and Configuring the DS-4900B
e. Complete the remaining prompts or press Ctrl-D to accept the
remaining settings without completing all the prompts.
f. Reenable the switch by entering the switchEnable command.
3. Optionally, specify any custom status policies:
a. Enter the switchStatusPolicySet command at the prompt. This
command sets the policy parameters that determine overall
switch status.
b. Customize the status policies as desired. To deactivate the
alarm for a condition, enter 0 at the prompt for that condition.
For more information, refer to the Fabric OS Administrator’s Guide
and the Fabric OS Comand Reference Manual.
Install SFPs and cable
the switch
To install SFPs and cable the switch:
1. Install the SFP transceivers in the Fibre Channel ports, as
required. The ports selected for use in trunking groups must meet
specific requirements. For a list of these requirements, see the
Fabric OS Administrator’s Guide.
a. Remove the plugs from the ports to be used.
b. Position a transceiver so that it is oriented correctly and insert
it into a port until it is firmly seated and the latching
mechanism clicks.
Note: The transceivers are keyed to ensure correct orientation. If a
transceiver does not install easily, ensure that it is correctly oriented.
c. Repeat steps a and b for the remaining ports, as required.
2. Connect the cables to the transceivers.
CAUTION
A 50-micron cable should not be bent to a radius less than 2 in.
under full tensile load and 1.2 in. with no tensile load.
Tie wraps are not recommended for optical cables because they
are easily overtightened.
