Interpreting LED activity
3-3
Operating the DS-4900B
Figure 3-1 LEDs on Port Side of the DS-4900B
1 DS-4900B 8 Port 0 Status LED
2 System Status LED 9 Port 4 Status LED
3 System Power LED 10 Ports 0 through 7
4 Console Port 11 Port 32 Status LED
5 Ethernet Port 12 Port 36 Status LED
6 Ethernet Speed LED 13 Ports 32 through 39
7 Ethernet Link LED
Scale:
1/4" = 1"
32 36 33 37 34 38 35 39
0 4 1 5 2 6 3 7
40 44 41 45 42 46 43 47
8 12 9 13 10 14 11 15
48 52 49 53 50 54 51 55
16 20 17 21 18 22 19 23
56 60 57 61 58 62 59 63
24 28 25 29 26 30 27 31
!
IOIOI
32 36 33 37 34 38 35 39
0 4 1 5 2 6 3 7
!
IOIOI
1
7643
2
5
98
10
131211
To Next Page
