Verifying system status
23
2. Verify that the SP Power LEDs on SP A and SP B located at the rear of the DPE are solid green
and the SP Fault LED is off as shown in Figure 13.
Note: If any fault LEDs are on, or if any power LEDs remain flashing after approximately 15 minutes
of operation, contact your authorized service provider.
Figure 13 SP LEDs
Make sure the power-up is complete before you continue with the next task.
