EMC VNX5300 Block

34 EMC VNX5300 Block Installation Guide
Verify 2U, 25 2.5” drive DAE status
1. Verify that the status of the 2U DAE Power LED located on the front is solid blue and the DAE
Fault/Status is off as shown in Figure 23.
2. If any fault LEDs are on, or if any power LEDs are flashing, contact your authorized service
provider.
Figure 23 2U, 25 2.5" drive DAE LEDs
0
24
Front
2U, 25 Disk-array enclosure
VNX-000233
DAE Fault/Status DAE Power
Disk drive
Power
Disk drive
Fault/Status
