Planning Worksheets
41
Planning Worksheets
VNX Block Configuration Worksheet
With your network administrator, determine the IP addresses and network parameters you plan to
use with the storage system, and record the information on the following worksheet. You must
have this information to set up and initialize the system.
You manage the storage system through a dedicated LAN port on each storage processor. These
ports must share a subnet with the host you use to initialize the system. After initialization, any
host on the same network and with a supported browser can manage the system through the
management ports.
Record network information for your system on the worksheets on the next pages. Your network
administrator should provide most of this information. For more information, refer to your
configuration planning guide.
Note: Do not use 128.221.1.248 through 128.221.1.255, 192.168.1.1, or 192.168.1.2 for an IPv4 IP
address.
Table 6 IPv4 Management Port Information
IP Address Subnet mask Gateway
SP A
SP B
Table 7 IPv6 Management Port Information (optional; manual configuration only)
Global prefix
Gateway
Table 8 Login information for the storage system administrator
Field Description Value
Username User choice
Password User choice
Storage-system
serial number
The serial number is located
on the PSNT tag hanging from
the rear of the DPE chassis.
The number is identified as
SN/Product ID.
Scope Global or Local
