3
Introduction.
The “MTOWER PLUS” is a fully featured cooling towers controller with two-way biocide options and inhibitor / bleed
control.Cooling towers are heat removal devices used to transfer process waste heat to the atmosphere. Cooling towers
may either use the evaporation of water to remove process heat and cool the working uid to near the wet-bulb air
temperature or rely solely on air to cool the working uid to near the dry-bulb air temperature. Common applications
include cooling the circulating water used in oil reneries, chemical plants, power plants and building cooling.
All information is provided through a large backlit LCD display (240x64). Using a revolutionary wheel control the instrument
can be easily programmed. “MTOWER PLUS” is housed in a IP65 plastic box.
Measures are: L325 x H235 x D125 (including wheel and connectors).
Main features of “MTOWER PLUS” are:
BLEED
INHIBITOR with 5 working modes
(Feed&Bleed, Feed&Bleed Percentual , PercenutalTime, WaterMeter, WaterMeter PPM)
BIOCIDE with weekly program
Conductivity, pH and ORP Meter with Proportional and Digital outputs
The wheel.
Located in the upper right side of “MTOWER PLUS” there is a wheel used to control the instrument.
Wheel can be rotated in both directions to scroll over menus and / or pressed to conrm highlighted selection / value.
- Edit single eld submenu by pressing wheel twice.
- When in main screen keep wheel pressed to switch “OFF” instrument. Repeat procedure to switch “ON” instrument.
Rotate the wheel to cycle-loop
through all available options.
Clockwise or Counterclockwise.
Press wheel to move
on submenu for selected option.
To Next Page
