Installation, Operation and Maintenance Manual
MAN-02-04-97-0713-EN Rev. 1
October 2019
93
Section 11: Maintenance
Maintenance
Figure 80
NOTICE
The new battery must be the same type as the one provided: Lithium – SAFT LS 9V.
NOTICE
To check the battery status, press the STOP button for at least 3 seconds. In any event, the
battery status is automatically checked at least once a day. The expected battery life is up to
4 years but this can vary depending on frequency of usage and environmental conditions.
Battery life may be reduced at high and low temperatures.
WARNING
If the actuator is located in a hazardous area, a hot work permit must be obtained unless
the actuator can be moved to a non-hazardous area.
Figure 81
