October 2019
Installation, Operation and Maintenance Manual
MAN-02-04-97-0713-EN Rev. 1
124
Appendix
Appendix
Appendix B: XTE3000 / XTE3000AD /
XTE3000LP
Ex db h IIB T4 Gb / Ex h tb IIIC T135°C Db IP66/68
Ex db h ia IIB T4 Gb / Ex h tb IIIC T135°C Db IP66/68
B.1 Safety Instructions
B.1.1 General
This Appendix B supplemental to Installation, Operation, and Maintenance Manual
MAN-02-04-97-0713 and prescribes the Safety Instructions applicable to electric actuators
of Series XTE3000 / XTE3000AD / XTE3000LP either as a base unit or when they are
equipped with:
a. an additional entry mounted on the control compartment or when they
are equipped with an optional extension
b. additional entries or with an optional extension
c. an optional electronic card mounted on the terminal board compartment, as
shown in Figure B-3. The subject actuator is certied according to EN and IEC
standards 60079-0, 60079-1, 60079-7, 60079-11 and 60079-31 and EN ISO
80079-36, 80079-37, for protection type Ex db h or Ex db h ia for gas group
IIB and Ex h tb for dust group IIIC. The actuator is suitable for installation in an
ambient temperature range from -25°C (-13°F) to +60°C (+140°F).
WARNING
Installation, conguration, commissioning, maintenance, and repairs must be performed
by approved and qualied personnel only.
Both the base unit XTE3000 and optional extension are designed in accordance with the
applicable international rules and specications, but the following regulations must be
observed in every case:
• The general installation and safety regulations.
• The proper use of personal protective devices (glasses, clothing, gloves).
• The proper use of tools, lifting and transport equipment.
