Section 13: Parts List and Drawings
Parts List and Drawings
Section 13: Parts List and Drawings
This Section includes the drawings and parts list of each component and sub-assembly of
the XTE3000.
CAUTION
Using a fastener other than the approved type may result in damage to the actuator or valve.
NOTICE
- When ordering spare parts, be sure to indicate the serial number embossed on the
actuator nameplate.
- When ordering spare parts, refer to the item number on the attached drawings.
Figure 89 Component Parts
