Emerson Bettis XTE3000 User Manual

October 2019
Installation, Operation and Maintenance Manual
MAN-02-04-97-0713-EN Rev. 1
106
Section 13: Parts List and Drawings
Parts List and Drawings
Table 21.
Item Qty Description
1 1 Housing
2 1 Lower bearing
3 1 Hollow shaft
4 1 Worm wheel
5 1 Circlip
6 1 Driver sleeve
7 1 Driver sleeve spring
8 1 Spring retaining ring
9 * 1 Seal kit
9.1 * 1 O-ring
9.2 * 1 Seal ring
9.3 * 1 Q-ring
9.4 * 1 O-ring
9.5 * 1 O-ring
9.6 * 1 O-ring
9.7 * 1 Seal ring
9.8 * 1 O-ring
9.9 * 1 O-ring
9.10 * 1 O-ring
9.11 * 1 Q-ring
9.12 * 1 O-ring
9.13 * 1 Seal ring
9.14 * 1 O-ring
9.15 * 2 O-ring
9.16 * 1 Seal ring
10 1 Upper bearing
11 2 Cover retaining ring
12 2 Plug
13 1 Cover shoulder washer
14 1 Cover
15 1 Handwheel
16 1 Oil plug
17 4 Screw
18 1 Stem protection tube
19 1 Taper bearing
20 1 Worm shaft
21 1 Taper bearing
22 1 Worm shaft ange
23 2 Screw
24 4 Screw
