Installation, Operation and Maintenance Manual
MAN-02-04-97-0713-EN Rev. 1
October 2019
129
Appendix
Appendix
B.7 Installation
NOTICE
Installation must be carried out in accordance to the applicable standards IEC/EN 60079-14
and IEC/EN 60079-17 regarding the electrical installations in Hazardous Areas (other than
mines) classied as Zones 1, 2 (gas) and Zones 21, 22 (dust) following IEC/EN 60079-10-1
and IEC/EN 60079-10-2 and any other applicable national standards and rules.
B.7.1 Working Condition
WARNING
Verify that the actuator nameplate conforms to the applicable certication, ambient
temperature range, and site safety requirements.
B.7.1.1 Models and Temperature
XTE-010 and XTE-020
from - 60°C to +65°C (from -76°F to +149°F)
from - 60°C to +85°C (from -76°F to +185°F)
XTE-030, XTE-040 and XTE-050
from - 55°C to +65°C (from -67°F to +149°F)
from - 55°C to +85°C (from -67°F to +185°F)
B.7.1.2 Base Unit With Extensions [A] or [B] or [C]
When an extension is installed on a base XTE3000 unit, the whole assembly
is suitable for the following ambient temperatures:
XTE-010 and XTE-020
from – 20°C to +65°C (from -4°F to +149°F)
from – 20°C to +85°C (from -4°F to +185°F)
XTE-030, XTE-040 and XTE-050
from – 20°C to +65°C (from -4°F to +149°F)
from – 20° C to +85°C (from -4°F to +185°F)
For all models the maximum permissible temperature depends on the type of
motor (SM, TM, DM, or LP) installed on the base XTE3000 unit.
