October 2019
Installation, Operation and Maintenance Manual
MAN-02-04-97-0713-EN Rev. 1
90
Section 11: Maintenance
Maintenance
11.3 Lithium Battery Change
• Isolate the main supply to the actuator and all other control voltages.
• Remove the terminal board cover.
• Disconnect two wires (+) (-) from the main board.
• Bring the cover to a safe area. When in this safe area:
— Remove the label.
Figure 72
Figure 73
To Next Page
