Installation, Operation and Maintenance Manual
MAN-02-04-97-0713-EN Rev. 1
October 2019
107
Section 13: Parts List and Drawings
Parts List and Drawings
Item Qty Description
25 * 1 Electric motor assembly
26 1 Motor cover
27 4 Screw
28 1 Oil plug
29 * 1 Finger assembly
30 2 Screw
31 1 Bush
32 1 Shoulder washer
33 1 Fork
34 1 Bearing bush
35 1 Lever washer
36 1 Lever assembly
37 1 Lever screw block
38 1 Screw
39 1 Earth stud
40 2 Earth stud nut
41 2 Washer
42 1 Earth stud indication plate
43 2 Bearing
44 1 Position sensor shaft
45 2 Screw
46 1 Absolute Encoder ange
47 * 1 Absolute Encoder assembly
48 3 Screw
49 4 Column
50 * 1 Power card
51 4 Column
52 4 Screw
53 * 1 Processor card
54 1
Power card cover (only for
models 010, 020, 030)
55 1 Local interface assembly
56 8 Screw
57 1 Screw
59 * 1 Terminal board
60 1 Circlip
61 1 Power terminals cover
62 2 Screw
63 4 Screw
64 1 Terminal board plate
65 1 Terminal board cover
70 1 Data plate
71 1 Circlip
75 1 Thrust block assembly
76 4 Screw
Optional
A * 1 Bus interface card
B 1 Battery assembly
*Recommended spare parts
