October 2019
Installation, Operation and Maintenance Manual
MAN-02-04-97-0713-EN Rev. 1
38
Operating the XTE3000
Section 5: Operating the XTE3000
Figure 46 Top View of Base Card
Top View of Base Card
Base card equipped with eldbus interface card and Terminal Board Adapter (TBA) card.
Figure 47 Fieldbus interface card
Fieldbus interface card
The type of card depends on the eldbus present in the plant.
Figure 48 Ain/Aout card
Ain/Aout card
This optional card is used in place of the Terminal Board Adapter (TBA) card when an analog
4-20 mA input and output signal is requested.
