Installation, Operation and Maintenance Manual
MAN-02-04-97-0713-EN Rev. 1
October 2019
41
Section 6: Local Controls
Local Controls
Table 9. List
output torque mot temp
motor speed term temp
main voltage log status
current wireless report
temperature node report *
time FDI report *
date base report
alarm term report
warning Ain/Aout report *
Ktemp
The data with * are only present if the relevant modules are present.
2. 3-position selector to set the following operation modes:
• LOCAL: for local control only
• OFF: no control is active but the actuator is still connected to the mains
• REMOTE: for remote control only
3. The XTE3000 can be provided with a radio-frequency wireless connection based on
a qualied Bluetooth class 1 module. This allows exchange of data with a PDA or PC with
built-in Bluetooth™ technology. The following tasks can be wirelessly performed:
• View and change conguration
• Set maintenance function
• Read maintenance data
• Download new rmware to the XTE3000
• The blue LED indicates that communication with a host device is established
4. Numeric display to indicate the present valve position as a % of open position.
Display resolution is a function of the number of complete turns of the actuator
output shaft:
• From 2 to 4 turns = 0.2%
• From 4 to 8,000 turns = 0.1%
5. Three LEDs to indicate the actuator status according to the following logic:
• green ON/ red OFF: the actuator is stopped in the open position
• green OFF/ red ON: the actuator is stopped in the closed position
• green OFF/ red ashing: the actuator is running in the closing direction
• green ashing/ red OFF: the actuator is running in the opening direction
• green ON/ red ON: the actuator is stopped in an intermediate position
• yellow ON: alarm
• yellow ashing: warning
The above color combination is supplied as standard, but it may be changed
(red to green, green to red, and yellow to red), during actuator setup operations.
