Emerson Bettis XTE3000 User Manual

Installation, Operation and Maintenance Manual
MAN-02-04-97-0713-EN Rev. 1 October 2019
43
Section 6: Local Controls
Local Controls
The alarm and warning lists only contain the present alarms and warnings. When the fault
condition disappears, the corresponding alarm or warning disappears from the list. A reset
routine is provided to clear the type of alarm/warning that is memorized (over-torque,
jammed valve, etc.).
The following drawing shows the use of the OPEN / YES, CLOSE / NO and STOP
push-buttons as a function of the local selector position.
Figure 53
Local Off Remote
3-position selector
= OPEN/YES push-button
= CLOSE/NO push-button
= STOP push-button
XTE3000 XTE3000 XTE3000
Graphic display
Only OPEN,
CLOSE and STOP
controls available
Language
selection
View mode
Set-up mode
To view
menus
To set-up
menus
View/Set-up mode
selection
Place the
3-position
selector in LOCAL
or REMOTE or
press YES and NO
simultaneously
to exit from
VIEW and SET-UP
MENUS
View and Setup menus
Press YES and STOP
simultaneously to
enter VIEW and
SET-UP menus
Press YES or NO to answer the
prompt (view? next?).
If the prompt is “next?” press YES to
view the next variable; press NO to
return to the beginning.
If the prompt is “view?” press
YES to enter the sub-menu of the
variable; press NO to skip to the
next variable.
YES
YES
YES
YES
YES
YES
YES
NO
NO
YES
NO
Variable alarm
and report list
TORQUE % next?
MOTOR SPEED RPM next?
VOLTAGE V,Hz next?
CURRENT A next?
TEMPERATURE °C next?
TIME next?
DATE next?
NO ALARMS/ALARMS next/view?
NO WARNING/WARNINGS next/view?
K TEMP or POWER TEMP
(ICON LP) next?
MOTOR TEMP °C next?
TERM TEMP next?
LOG STATUS next?
WIRELESS REPORT view?
WIRELESS CONNECT view?
NODE REPORT view?
FDI REPORT view?
BASE REPORT view?
TERM REPORT view?
A in /A out REPORT view?
ALARM # 1 next?
..................
..................
ALARM # n next?
RESET ALARMS OK?
WARNING # 1 next?
..................
..................
WARNING # n next?
RESET WARNING OK?
msg # 1 next?
..................
..................
msg # n next?
XXXXXX REMOTE
XXXXXX NEXT?
XXXXXX OFF
STOP NEXT?
XXXXXX LOCAL
XXXXXX ?
Password
NO
= OPEN/YES push-button
