Emerson Bettis XTE3000 User Manual

October 2019
Installation, Operation and Maintenance Manual
MAN-02-04-97-0713-EN Rev. 1
54
Section 9: Set-Up Routines
Set-Up Routines
Close limit by torque
• Move the local selector to LOCAL. The local controls can be used.
• Press the CLOSE control. The actuator will move in the closing direction and when
the congured torque value is reached, the motor will stop and the new position
limit is memorized.
• Move the local selector to OFF.
• Press YES to conrm.
• Press YES to continue with the close limit setting, or press NO and again NO to
repeat the close limit setting procedure. Press NO and then YES to exit from the
stroke limits routine.
Open limit type
• Press YES if the open limit type is correct (torque or position); otherwise,
press NO to change it.
• Press YES to conrm.
Open limit by position
• Move the local selector to LOCAL. The local controls become active.
• Move the valve to the open position (via the OPEN command or via the handwheel).
• Move the local selector to OFF.
• Press YES to conrm.
• Press YES to exit, or press NO and then YES to repeat the close limit setting procedure.
Open limit by torque
• Move the local selector to LOCAL. The local controls become active.
• Press the OPEN control. The actuator will move in the opening direction and when
the congured torque value is reached, the motor will stop and the new position
limit is memorized.
• Move the local selector to OFF.
• Press YES to conrm.
• Press YES to exit or press NO and then YES to repeat the close limit setting procedure.
If the parameter “direction to close” is changed, both limits (open and close) must be set.
Table 11.
Valve type Close Limit Open Limit
Gate (solid, exible and split wedge), globe,
metal-seated buttery valves
Torque Position
Ball, gate (parallel slide), plug valves, rubber-seated
buttery valves
Position Position
Linear valves with back-seating on stem Torque or Position Torque
Before leaving the stroke limits routine the microprocessor calculates the new value of
the position resolution. If the stroke turns are fewer than 2.7, the message “error re-try”
appears and the stroke limits procedure must be repeated.
