Chapter 5 iCOM Controller 39
Liebert. PEX+Series Precision Air Conditioner User Manual
Parameters
Default
Description
S085
BONUS
0MM
Bonus amount. Actual bonus calculated through the number of starts and average run time.
This value determines the time for the next maintenance
WELLNESS ECO
Table 5-22 Descriptions of WELLNESS ECO parameters
Parameters
Default
Description
S090
REPOS
-
Number of Repositions
S091
RUN HRS
hr
Economizer Run Hours
S092
REP/HR
-
Economizer Repositions per Hour
5.7.5 DIAGNOSTICS
The DIAGNOSTICS menu is classified into two groups. After entering the menu, pressing the up button and DOWN
button can switch between two groups and pressing the ENTER button can enter the parameters of the corresponding
group. The parameters of group 1 are settable and used to help the maintenance personnel start and cut off devices
by hand in site, so as to realize the diagnosis for devices. The parameters of group 2 are read only and reflect the fault
condition of the devices. See Table 5-23 for detailed descriptions.
Table 5-23 Descriptions of DIAGNOSTICS parameters
Parameters
Default
Setting range
Description
Group 1
S302
HP1 CODE
0
-
HP 1 alarm counting. The counter can be reset to 0 through
the parameter
S303
HP2 CODE
0
-
HP 2 alarm counting. The counter can be reset to 0 through
the parameter
S304
HT1 CNT
0
-
HT 1 alarm counting. The counter can be reset to 0 through
the parameter
S305
HT2 CNT
0
-
HT 2 alarm counting. The counter can be reset to 0 through
the parameter
S306
LP1 CODE
0
-
LP 1 alarm counting. The counter can be reset to 0 through
the parameter
S307
LP2 CODE
0
-
LP 2 alarm counting. The counter can be reset to 0 through
the parameter
S308
LP1 ACT
br
-
Actual LP 1
S309
LP2 ACT
br
-
Actual LP 2
S310
HP1 ACT
br
-
Actual HP1 Pressure
S311
HP2 ACT
br
-
Actual HP2 Pressure
S313
MANUAL
No
Yes, No
Selecting ‘Yes’ can turn on or off the components; selecting
‘No’ can prohibit manual setting
S314
MOTOR(S)
On
On, Off
Diagnosis switch of fan motor. The settings ‘On’ and ‘Off’ are
used to manually start and shut down the fan respectively
S315
COMP1
-
Off, On
Semi Manual Compressor 1 Request
S315
C1 MODE
Run
Run, Evac,
Charg
Compressor 1 operation mode selection
S317
C1 CAP
Off
On, Off
Refrigeration capacity output of digital scroll compressor 1
S318
C1 CYCLE
0%
-
-
S319
LLSV 1
Off
On, Off
Diagnostic of liquid line solenoid valve of compressor 1
S320
C2 MODE
Run
Run, Evac,
Charg
Compressor 2 operation mode selection
S322
C2 CAP
Off
-
Refrigeration capacity output of digital scroll compressor 2
S32A
C2 CYCLE
0%
-
-
S32B
LLSV2
Off
On, Off
Diagnosis switch of liquid line solenoid valve of compressor 2
S324
EL HEAT1
Off
On, Off.
Diagnosis switch of electric heater 1. The ‘On’ setting of this
parameter can start electric heater 1 only when the air loss is
normal
S325
EL HEAT2
Off
On, Off.
Diagnosis switch of electric heater 2. The ‘On’ setting of this
parameter can start electric heater 2 only when the air loss is
normal
