46 Chapter 5 iCOM Controller
Liebert. PEX+Series Precision Air Conditioner User Manual
5.8 ADVANCED MENUS
The ADVANCED MENUS include PASSWORD LEVEL, FACTORY SETUP and PASSWORDS, as shown in Figure
5-11.
Figure 5-11 ADVANCED MENUS
5.8.1 PASSWORD LEVEL
It is operated by Emerson service personnel.
5.8.2 FACTORY SETUP
The FACTORY SETUP menu is displayed in nine pages. The parameters are described in Table 5-30 ~ Table 5-39.
Unit code related settings
Table 5-30 Descriptions of unit code related settings
Parameters (1/9)
Default
Setting range
Description
A003
UC 01
0
-
Unit code setting. The code has 18 bits. Each bit can be set as 0 ~
20
…
…
…
A003
UC 06
0
A005
UC 07
0
…
…
…
A005
UC 12
0
A007
UC 13
0
…
…
…
A007
UC 18
0
A008
UC CTRL
No
Save, Load,
Compare, No
Options include:
Save: after UC01 ~ UC18 are changed, the changed can be saved
through the save command.
Load: load parameters to the unit code directly.
Compare: compare the present parameters and the parameters to
be loaded.
No: All changes are cancelled. Keep the old parameters
A009
UC STAT
OK
Not available,
Invalid, OK,
Changed,
Updating
Unit code status. Range:
Not available: parameters set through UC01 ~ UC18 are
unavailable.
Invalid: parameters set through UC01 ~ UC18 are invalid.
OK: parameters set through UC01 ~ UC18 are effective.
Changed: parameters UC01 ~ UC18 are changed, but not saved.
Updating: parameters are updating
A010
EL CTRL
Load
-
External data can be loaded through the load command
A011
EL STAT
OK
Not available,
Invalid, OK,
Changed,
Updating
Exception list status. Range:
Not available: parameters set through UC01 ~ UC18 are
unavailable.
Invalid: parameters set through UC01 ~ UC18 are invalid.
OK: parameters set through UC01 ~ UC18 are effective.
Changed: parameters UC01 ~ UC18 are changed, but not saved.
Updating: parameters are updating
ADVANCED MENUS
1 / 2
PASSWORD LEVEL
FACTORV SETUP
3 ? ???
SET
PASSWORDS
2 / 2
ACCESS
ADVANCED MENUS
