Emerson Liebert PEX+ Series - Page 57

Chapter 5 iCOM Controller 49
Liebert. PEX+Series Precision Air Conditioner User Manual
Table 5-37 Descriptions of analog output options
Options
Description
Options
Description
CW010
CW/FC 0 ~ 10V
ALBD2
AlarmBoard 2
HW
Hot water
ALBD3
AlarmBoard 3
HW175
Hot water 1.75
IVAR
I-Variex 1
VSD
Variable fan speed drive
HUM%
HT HUM
COOL
Cooling
SUP
Supply Temperature
CV175
CW/FC 1.75
RET
Return Temperature
COOL1
Cooling 1
HUMI
Humidifier
COOL2
Cooling 2
SUPSA
Supersaver
HEAT
Heater
INVCO
Inverted Cool
No
No use
HEAT3
Heating 33%
MBV1
Motorized ball vavle1
CW210
CW/FC 2 ~ 10V
MBV2
Motorized ball vavle 2
C2010
CW2 0 ~ 10V
SCR
Silicon controlled rectifier
C2175
CW2 1.75
CONF
Configurable
C2210
CW2 2 ~ 10V
ALBD1
AlarmBoard 1
Analog action related settings
Table 5-38 Descriptions of analog action related settings
Parameters (8/9)
Default
Setting range
Description
A168
AO1 STA
0%
0% ~ 100%
Analog output 1 start percentage
A168
AO1 STA
0V
0V ~ 10V
Analog output 1 start voltage
A169
AO1 END
100%
0% ~ 100%
Analog output 1 end percentage
A169
AO1 END
10V
0V ~ 10V
Analog output 1 end voltage
A170
AO2 STA
0%
0% ~ 100%
Analog output 2 start percentage
A170
AO2 STA
0V
0V ~ 10V
Analog output 2 start voltage
A171
AO2 END
100%
0% ~ 100%
Analog output 2 end percentage
A171
AO2 END
10V
0V ~ 10V
Analog output 2 end voltage
A172
AO3 STA
0%
0% ~ 100%
Analog output 3 start percentage
A172
AO3 STA
0V
0V ~ 10V
Analog output 3 start voltage
A173
AO3 END
100%
0% ~ 100%
Analog output 3 end percentage
A173
AO3 END
10V
0V ~ 10V
Analog output 3 end voltage
A174
AO4 STA
0%
0% ~ 100%
Analog output 4 start percentage
A174
AO4 STA
0V
0V ~ 10V
Analog output 4 start voltage
A175
AO4 END
100%
0% ~ 100%
Analog output 4 end percentage
A175
AO4 END
10V
0V ~ 10V
Analog output 4 end voltage
LL related settings
Table 5-39 Descriptions of LL related settings
Parameters (9/9)
Default
Setting range
Description
A179
LL1 LOW
%
0 ~ 100%
HPT1 low limit percentage setting
A179
LL1 LOW
br
10.0 ~ 50.0br
HPT1 low limit set point
A180
LL1 HIGH
%
0 ~ 100%
HPT1 high limit percentage setting
A180
LL1 HIGH
br
10.0 ~ 50.0br
HPT1 high limit set point
A181
LL1 ACT
%
-
HPT1 actual percentage, read only
A182
LL1 ACT
br
-
HPT1 actual value, read only
A183
LL2 LOW
%
0 ~ 100%
HPT2 low limit percentage setting
A183
LL2 LOW
br
10.0 ~ 50.0br
HPT2 low limit set point
A184
LL2 HIGH
%
0 ~ 100%
HPT2 high limit percentage setting
A184
LL2 HIGH
br
10.0 ~ 50.0br
HPT2 high limit set point
A185
LL2 ACT
%
-
HPT2 actual percentage, read only
A186
LL2 ACT
br
-
HPT2 actual value, read only
A187
REM SHUT
Closed
CLSON,OPNON
Remote Shutdown
A188
MM OVR
No
-
Manual Mode Override
