Emerson Liebert PEX+ Series - Network Setup

44 Chapter 5 iCOM Controller
Liebert. PEX+Series Precision Air Conditioner User Manual
5.7.8 NETWORK SETUP
The NETWORK SETUP menu is used to set the parameters when the system is in a network subject to the monitoring
of a host. See Table 5-28 for parameter descriptions.
Table 5-28 Descriptions of NETWORK SETUP parameters
Parameters
Default
Setting range
Description
S802
#UNITS
1
1 ~ 32
Range: 1 ~ 32
S803
TEAMWORK
No
No, 1, 2
Range: No, 1, 2
S824
MON ADD
3
1 ~ 99
Monitoring address No. of the unit
S825
MON T.O.
No
No, 1, 2
Monitoring Timeout
S825
MON H.S.
3
1 ~ 99
Monitoring Handshake
S830
UPGRSTAT
-
None,S CS,
S NS,S SR,
S GDR,
SBLV,SRAM,
Ready,Fail
Lock for Upgrade Status
S830
UPGRADE
-
No,Yes,
ULock
Lock for Upgrade
S831
CS CTRL
No
Save, Load,
No
Save the parameter set through MON ADD to the iCOM controller.
‘No’ means not saved
S831
CS STAT
Change
Change, Valid
Indication of the saving state of the parameter set through MON
ADD. ‘Change’ means that the parameter is changed but not saved.
‘Valid’ means that the setting is valid and saved
S832
NW CTRL
No
Save, Load,
No
Save the parameter set through U2U GRP to the iCOM controller.
‘No’ means not saved
S832
NW STAT
Valid
Change, Valid
Indication of the saving state of the parameter set through U2U
GRP. ‘Change’ means that the parameter is changed but not saved.
‘Valid’ means that the setting is valid and saved
S835
MON PROT
Vlct4
No,Vlct3,HN,
IGM,n.a.,Vlct4
Host monitoring protocol setting. Range: Vlcty (Velocity uses
intelligent card), HN (Hironet), IGM (ECA2), No
S836
IP #1
192
-
Set IP address
S836
IP #2
168
S836
IP #3
254
S836
IP #4
1
S837
NM #1
255
-
Set subnet mask
S837
NM #2
255
S837
NM #3
255
S837
NM #4
0
S838
GW #1
0
-
Set gateway address
S838
GW #2
0
S838
GW #3
0
S838
GW #4
0
S840
U2U PROT
GBP
-
-
S841
U2U ADD
3
-
Group address No. of this unit
S842
U2U GRP
1
-
-
S843
BL CTRL
No
S + R, No
Boot program variant load. Saving the change of S835 ~ S841 needs
the S + R command of this parameter. The system will reset after the
saving, and configure according to the new parameters
S843
BL STAT
Valid
Change, Valid
Indication of whether or not the parameters set through S835 ~ S841
are saved. ‘Change’ means that the parameter is changed but not
saved. ‘Valid’ means that the setting is valid and saved
S844
SR CTRL
No
C + R, No
Static RAM data reset control. If the change of S835 ~ S841 are not
saved, using the C + R command in this parameter can restore S835
~ S841 to their original settings, and the system will reset afterwards
S844
SR STAT
Valid
-
STD
SW#
-
-
Version No. of the control software
MAC
-
-
MAC address of the network card of the iCOM controller
NAME
UNIT
UNIT
Name of the unit. By default: UNIT. You can change the name as
you need
