Figure 3-3: Wall-mounting bracket and dimensions for an aluminum
transmitter
A. 2.8 in (71 mm)
B. 2.8 in (71 mm)
Figure 3-4: Wall-mounting bracket and dimensions for a stainless steel
transmitter
A. 7.51 in (190.8 mm)
B. 3.67 in (93.2 mm)
