ROC800-Series Instruction Manual
Revised July-2017 Installation and Use 2-1
Chapter 2 – Installation and Use
In This Chapter
2.1 Installation Requirements ....................................................................... 2-1
2.1.1 Environmental Requirements ....................................................... 2-2
2.1.2 Site Requirements ....................................................................... 2-2
2.1.3 Compliance with Hazardous Area Standards .............................. 2-3
2.1.4 Power Installation Requirements ................................................. 2-3
2.1.5 Grounding Installation Requirements .......................................... 2-4
2.1.6 I/O Wiring Requirements .............................................................. 2-5
2.2 Required Tools ........................................................................................ 2-5
2.3 Housing ................................................................................................... 2-5
2.3.1 Removing and Replacing End Caps ............................................ 2-5
2.3.2 Removing and Installing Wire Channel Covers ........................... 2-6
2.3.3 Removing and Installing Module Covers ..................................... 2-6
2.4 Mounting the ROC800 on a DIN Rail ...................................................... 2-7
2.4.1 Installing the DIN Rail .................................................................. 2-8
2.4.2 Securing the ROC800 to the DIN Rail ......................................... 2-9
2.4.3 Removing the ROC800 from the DIN Rail ................................... 2-9
2.5 ROC800-Series Expansion Backplane (EXP) ........................................ 2-9
2.5.1 Attaching an Expansion Backplane ........................................... 2-10
2.5.2 Removing an Expansion Backplane .......................................... 2-11
2.6 Central Processing Unit (CPU) ............................................................. 2-13
2.6.1 Removing the CPU Module ....................................................... 2-17
2.6.2 Installing the CPU Module ......................................................... 2-17
2.7 License Keys ......................................................................................... 2-18
2.7.1 Installing a License Key ............................................................. 2-19
2.7.2 Removing a License Key ........................................................... 2-19
2.8 Startup and Operation........................................................................... 2-20
2.8.1 Startup ........................................................................................ 2-20
2.8.2 Operation ................................................................................... 2-21
This chapter describes the ROC800-Series housing (case), backplane
(electronic connection board at the back of the housing), CPU (central
processing unit), and the expansion backplane (EXP). This chapter
provides a description and specifications of these hardware items and
explains installation and startup of the ROC800-Series.
2.1 Installation Requirements
The ROC800’s design makes it highly adaptable to a wide variety of
installations. Consequently, this manual cannot cover all possible
installation scenarios. Contact your local sales representative if you
require information concerning a specific installation not described in
this manual.
Planning is essential to a good installation. Because installation
requirements depend on many factors (such as the application, location,
ground conditions, climate, and accessibility), this document only
provides generalized guidelines.
