ROC800-Series Instruction Manual
Revised July-2017 Power Connections 3-25
I/O Module
Power Consumption (mW)
Quantity
Used
Duty
Cycle
Sub-Total
(mW)
Description
P
TYPICAL
PM-30 (24V) Joining
Network
912 mW
1
PM-30 (30V) Joining
Network
900 mW
1
Pm-12 (12V) linked to
Network
240 mW
1
Pm-24 (24V) linked to
Network
240 mW
1
PM-30 (12V) linked to
Network
396 mW
1
PM-30 (24V) linked to
Network
360 mW
1
PM-30 (30V) linked to
Network
360 mW
1
Table Total
Duty Cycle
An NRM has no associated duty cycle. Consequently, always set “1”
as the duty cycle value.
Table 3-22. Power Consumption of Other Devices
Other Device
Power Consumption (mW)
Quantity
Used
Duty
Cycle
Sub-Total
(mW)
Description
P
TYPICAL
Total
Although Table 3-5 and Tables 3-6 through 3-20 take into account the
power the ROC800 supplies to its connected devices, be sure to add the
power consumption (in mW) of any other devices (such as radios or
solenoids) used with the ROC800 in the same power system, but which
are not accounted for in Tables 3-6 through 3-18.
Enter that Total value in the Other Devices line of Table 3-5.
3.3 Removing a Power Input Module
To remove the Power Input module:
