Pushing the Tubing Fitting OutFigure 12-7:
5. Remove and discard the pump tubing.
6.
Insert the new tubing one end at a time. Tongues on the sides of the gray fittings at
the end of the tube fit into receiving grooves in the pump casing. Push the fitting in
place until it clicks. Gently stretch the tubing over the rollers and insert the other
fitting into the receiving socket on the other side of the pump.
See Figure 12-8.
Inserting New TubingFigure 12-8:
7. Replace the pump cover.
a.
Place the cover on the pump casing.
See Figure 12-9.
Maintenance
Manual 61
