6.4.12.5 FEEDING (WITH LOADCELL) GRAPHICS (EPC 3&4)
If there is loadcell in the system then FEED UNIT PAREMETERS PAGE UNIT parameter must set to
WEIGHT.
For example;
FEEDING PARAMETERS
F1: 06:00 150
F2: 10:00 200
F3: 12:00 100
F4: 19:00 100
F5: 22:00 200
HR:MN FEED<KG>
Start Time Feed Amount
FEED UNIT PARAMETERS
UNIT : WEIGHT
FEED PER MIN: 5.0KG
TARE : NO
REF WEIGHT : 250KG
TAKE REF WEIGHT: NO
FEED OFFSET : 0KG
FEEDING CONSUMPTION PAGE TOTAL CONSUMP changes as long as feeding digital input is ON
(independent from any step and any time)
ON
OFF
Time[sec]
Feeding
relay output
Required
Feed[kg]
0
Time [sec]
150
75
ON
OFF
Time[sec]
Feeding
digital
input
Feeding
Consum.
[kg]
0
Time [sec]
20600
20525
20450
20700
70
