6.4.13.8 WEIGHING ADJUSTMENT (EPC 4, EPC 4A)
1. Weighing adjustment steps:
To make weighing adjustment, WEIGHTX CALIBRATION pages are used.
- WEIGHT1 CALIBRATION page is used to make WEIGHT1 0-10V input
adjustment.
- WEIGHT2 CALIBRATION page is used to make WEIGHT2 0-10V input
adjustment
- WEIGHT3 CALIBRATION page is used to make WEIGHT3 0-10V input
adjustment
The explanation below is for WEIGHT1 CALIBRATION page but actually it is common explanation. So given
example is valid for each of three pages.
Adjustment steps
1. Take tare (TARE parameter)
2. Enter reference weight (REF WEIGHT parameter)
3. Take reference weight (TAKE REF WEIGHT parameter)
Access to WEIGHT1 CALIBRATION page
Push button to select TARE parameter
While the perch is empty push button to switch parameter’s value
to YES.
Almost 3 seconds later read weight is saved as tare weight and parameter’s
value will switch back to NO. Now push button and access to next
parameter. Using button enter 5000 gr and push button.
Thus, access to next parameter.
Put 5000 gr weigh into the perch (because of reference weight is 5000 gr
for this example).
Wait for a little time and push button to switch parameter to YES.
Almost 3 seconds later 5000 gr weigh is saved as reference weight and
parameter’s value switches back to NO.
WEIGHT1 CALIBRATION
TARE:
REF WEIGHT: 1000GR
TAKE REF WEIGHT: NO
0GR
NO
WEIGHT1 CALIBRATION
TARE:
REF WEIGHT: 1000GR
TAKE REF WEIGHT: NO
0GR
YES
WEIGHT1 CALIBRATION
TARE: NO
REF WEIGHT: GR
TAKE REF WEIGHT: NO
0GR
5000
WEIGHT1 CALIBRATION
TARE: NO
REF WEIGHT: 5000GR
TAKE REF WEIGHT:
0GR
NO
WEIGHT1 CALIBRATION
TARE: NO
REF WEIGHT: 5000GR
TAKE REF WEIGHT:
0GR
YES
WEIGHT1 CALIBRATION
TARE: NO
REF WEIGHT: 5000GR
TAKE REF WEIGHT:
5000GR
NO
WEIGHT1 CALIBRATION
TARE: NO
REF WEIGHT: 1000GR
TAKE REF WEIGHT: NO
0GR
