EMKO TRANS-AMF - Advanced J1939 and Status Display; J1939 Engine Parameters; J1939 Faults and I;O Status

DATE & TIME
15/02/2011
13:32:28
EXP. INPUT & OUTPUT
1 4 5 8
Inputs : 0000 0000
Outputs: 0000 0000
On load
INPUT & OUTPUT
1 4 5 8
Inputs : 0000 000X
Outputs: 0000 0000
On load
J1939 DM1 FAULTS1
Spn:110
Fmi:0 Oc:1
Coolant Temper.sensor
Value too high
J1939 VALUES
Int.man.temp.: 45ºC
Pedal position: 50.0%
W.Hour_Min: 2_57
On load
J1939 VALUES
Oil temper.: 82.00ºC
Act.engine torq: 75%
Boost press.: 2.8bar
On load
J1939 Values Page4:
Oil temper.: Oil temperature via J1939
Act.engine torq: Actual engine torque via J1939
Boost press.: Boost pressure via J1939
J1939 Values Page5:
Int.man.temp.: Intake manifold temperature via J1939
Pedal position: Accelerator pedal position via J1939
W.Hour_Min: Working hour and minute via J1939
J1939 DM1 (Active) Faults Page:
Spn: Suspect parameter number (e.g. SPN = 110 corresponds to
coolant temperature sensor)
Fmi: Failure mode identifier (e.g. FMI = 0 means value too high)
Oc: Occurrence count (if OC = 0, no alarm is present)
The first 10 active alarm messages (Active Diagnostic Trouble
Codes - DM1) with SPN, FMI, and OC are displayed). If more than
one active fault condition is present, all of them is displayed
sequencely by pressing Next and Previous buttons.
Input & Output Status Page:
Inputs: Input status information. If an input is active, related digit
is displayed as "1" else it is displayed as "0".
1: Conf. in-1, 2: Conf. in-2, 3: Conf. in-3, 4: Conf. in-4,
5: Conf. in-5, 6: Conf. in-6, 7: Conf. in-7, 8: Not available.
Outputs: Output status information. If an output is active, related
digit is displayed as "1" else it is displayed as "0".
1: Conf. out-1, 2: Conf. out-2, 3: Conf. out-3, 4: Conf. out-4,
5: Conf. out-5, 6: Conf. out-6, 7: Generator contactor,
8: Mains contactor.
Exp. Input & Output Status Page:
Inputs: Exp. input status information. If an input is active, related
digit is displayed as "1" else it is displayed as "0".
1: Exp. conf. in-1, 2: Exp. conf. in-2, 3: Exp. conf. in-3,
4: Exp. conf. in-4, 5: Exp. conf. in-5, 6: Exp. conf. in-6,
7: Exp. conf. in-7, 8: Exp. conf. in-8.
Outputs: Exp. output status information. If an output is active,
related digit is displayed as "1" else it is displayed as "0".
1: Exp. conf. out-1, 2: Exp. conf. out-2, 3: Exp. conf. out-3,
4: Exp. conf. out-4, 5: Exp. conf. out-5, 6: Exp. conf. out-6,
7: Exp. conf. out-7, 8: Exp. conf. out-8.
Date & Time Page:
Date: Day, Month, Year.
Time: Hour, minute, second.
