EMKO TRANS-AMF - Specific Data Displays; Warning and Alarm Messages

Warning & Alarm Page:
1/3: The first message of current alarms.
Emergency stop!: This message indicates that an emergency
stop alarm has occurred.
Event Log Page1:
1.1: The first page of related event log
Emergency stop: This message indicates that an emergency stop
alarm has occurred. (Event history: 15/02/2011 date, 14:26:08
time).
V1: Generator voltage L1-N
I1: Load Current L1
V2: Generator voltage L2-N
I2: Load Current L2
Event Log Page2:
1.2: The second page of related event log
V3: Generator voltage L3-N
I3: Load Current L3
Fq: Generator frequency
kW: Generator total active power
Oil oressure: Oil pressure sender input value
Coolant temp: Coolant temperature sender input value
Event Log Page3:
1.3: The last page of related event log
Conf. AI1: Configurable Analog Input-1 value
Conf. AI2: Configurable Analog Input-2 value
kWh: Generator active energy
Events (from 1 to 50) can be displayed sequencely with the Next
and Previous buttons.
13
WARNING&ALARM 1/3
Emergency stop!
EVENT LOG 1.1
15/02/2011 14:26:08
Emergency stop
V1: 220V I1: 26A
V2: 220V I2: 23A
EVENT LOG 1.2
V3: 220V I3: 25A
Fq:50.0Hz kW: 510
Oil pressure: 4.3bar
Coolant temp: 30ºC
EVENT LOG 1.3
Conf.AI1 : 96%
Conf.AI2 : 40ºC
kWh: 30600
Warning & Alarm display pages on the LCD display;
Event Log display pages on the LCD display;
GenSet Page: (This page is only available at TRANS-AMF.TR device)
VLn: Generator voltage L1-N, L2-N and L3-N
Amp: Generator current L1, L2 and L3
Hz: Generator frequency
bar: Oil pressure sender input value
kW: Generator total active power
ºC: Coolant temperature sender input value
cos: Generator power factor average
%: Configurable Analog Input-1 value
rpm: Engine speed
Vdc: Battery supply voltage
GENSET
VLn 220V 220V 220V
Amp 26A 23A 25A
50.0Hz 4.3bar
630kW 30ºC
1.00cos 96%
1500rpm 12.0Vdc
On load
