EMKO TRANS-AMF - Page 14

GENERATOR
kWh : 30600
kVArh: 7200
On load
ENGINE
Oil Pressure: 4.3bar
Temperature : 30ºC
Speed : 1500rpm
On load
ENGINE
Conf.AI1 : 96%
Conf.AI2 : 40ºC
Battery volt: 12.0Vdc
On load
MAINS
V12: 380V V1: 220V
V23: 380V V2: 220V
V31: 380V V3: 220V
Wait for start
MAINS
Fq:50.0Hz
Phase seq.: L1 L2 L3
Wait for start
GENERATOR
V12: 380V V1: 220V
V23: 380V V2: 220V
V31: 380V V3: 220V
On load
GENERATOR
I1: 26A PF1: -0.84
I2: 23A PF2: -0.80
I3: 25A PF3: -0.82
On load
GENERATOR
P1: 170kW
P2: 170kW
P3: 170kW
On load
GENERATOR
Fq:50.0Hz Ie: 0A
Phase seq.: L1 L2 L3
On load
GENERATOR
P: 510kW
Q: 120kVAr
S: 630kVA
On load
S
S
S
GENERATOR
S1: 210kVA
S2: 210kVA
S3: 210kVA
On load
GENERATOR
Q1: 40kVAr
Q2: 40kVAr
Q3: 40kVAr
On load
ENGINE
Gen.chg.volt: 11.8Vdc
Run times : 7
Crank times : 11
On load
ENGINE
W.Hour_Min: 2_57
Cabin temp: 26ºC
On load
ENGINE MAINTENANCE
Next hours : 5000
Next days : 180
Last date: 15/02/2011
On load
J1939 VALUES
Engine speed: 1500rpm
Oil pressure: 4.0bar
Coolant temp: 27ºC
On load
J1939 VALUES
Fuel rate: 12.50L/h
Fuel tot.: 176L
Oil level: 97.2%
On load
J1939 VALUES
Coolant level: 87.6%
Load at cur.spd: 25%
Fuel temper.: 13°C
On load
J1939 DM1 FAULTS1
Spn:110
Fmi:0 Oc:1
Coolant Temper.sensor
Value too high
J1939 VALUES
Oil temper.: 82.00ºC
Act.engine torq: 75%
Boost press.: 2.8bar
On load
J1939 VALUES
Int.man.temp.: 45ºC
Pedal position: 50.0%
W.Hour_Min: 2_57
On load
INPUT & OUTPUT
1 4 5 8
Inputs : 0000 000X
Outputs: 0000 0000
On load
EXP. INPUT & OUTPUT
1 4 5 8
Inputs : 0000 000X
Outputs: 0000 0000
On load
DATE & TIME
15/02/2011
13:32:28
Example-1: Displaying all Data display pages.
