EMKO TRANS-AMF User Manual

4.2 Technician Parameters
27
4.2.1 System
CT ratio
Load current transformers transfer ratio(Primary current/Secondary current) value must be entered to
this parameter.
Example:
If Current Transformer Primary=500A and Current Transformer Secondary=5A, Current Transformer
Ratio should be entered CT Primary/CT Secondary=100.
PT ratio
Defines the scaling factor applied to voltage readout and associated fault conditions.
This PT ratio is for additional voltage transformers mounted the unit.
CT location
Generator: The CTs are located to the generator side, so will show only generator load.
Load: The CTs are located to the load side, so will show generator or mains load provided by supply.
Min
Default
Unit
BREAKERS (System->Breakers)
Max
Hardware Breaker Selection
Gen Close Breaker Contact Type
Gen Close Breaker Relay Type
Gen Close Timer
0
Gen Open Breaker Relay Type
0 2
Gen Open Timer
Mains Close Breaker Contact Type
Mains Close Breaker Relay Type
Mains Close Timer
NO / NC
0
NOR / PULS
5
1 250
0
Sec
0
NOR / PULS
0
1 250
5
0
NOR / PULS
0
1 250
5
5
NOR / PULS
0.0
0.0
0
10.0
10.0
250
2
Mains Open Breaker Relay Type
Mains Open Timer
Breaker Close Pulse Time
Breaker Open Pulse Time
Transfer Time
Spring Loading Time
Retry Number
NO / NC
Gen.brk.cls.contact
Gen.brk.cls.relay
Gen.brk.cls.time
Gen.brk.open relay
Gen.brk.open time
Type of Breaker
Mains.brk.cls.relay
Mains.brk.cls.time
Mains.brk.open relay
Mains.brk.open time
Break.close puls.time
Mains.brk.cls.contact
Transfer time
Spring loading time
Retry number
Break.open pulse time
Sec
Sec
1 250
0.5
0.5
Sec
Sec
Sec
Sec
Sec
3
5
1 250
1 250
Hardware Breaker Selection
0- Breakers: Mains and Gen breakers have only close drives and if close drive off breaker will open.
Parameters; GEN CLOSE BREAKER CONTACT TYPE, GEN CLOSE TIMER(if gen closed input
selected), GEN OPEN TIMER(if gen closed input selected), MAIN CLOSE BREAKER CONTACT
TYPE, MAINS CLOSE TIMER(if mains closed input selected), MAINS OPEN TIMER(if mains closed
input selected), TRANSFER TIME.
Note-1 : NO / NC : Normally Open / Normally Close
2 : NOR / PULS : Normal / Pulse
Min
Default
Max
Current Transformer Ratio
Earth Fault Current Transformer Ratio
Voltage Transformer Ratio
Select AC system;
Generator Phase Sequence (dis, L123 or L321)
Generator kVA rating set
Power unit
Current Transformer Location;
kVA, kW, kVAr point position;
CT ratio
Earth fault CT ratio
PT ratio
Type of AC system
Phase sequence
Generator kVA rating
Power unit
CT location
kVA,kW,kVAr point
Unit
SYSTEM NETWORK (System->Network)
9999
3
9999
100
kVA
1
0
0
1
100
1
300
kVA
1
DISBL
0- 1 Phase 2 Wire
1- 3 Phase 4 Wire
2- 2 Phase 3 Wire L1-L2
3- 2 Phase 3 Wire L1-L3
DISBL, L123, L321
99991
100
kVA/kW
3
1
0
0
0
0
0-> 0
1-> 0.0
2-> 0.00
3-> 0.000
0-> Generator
1-> Load
