EMKO TRANS-AMF - Front Panel and Parameter Access; Front Panel Description

This LED indicates that a "Shutdown" alarm was detected.
1
2
4
5
6
7
9
12
13
14
Number
Comment
ü
1
2
3
4
5
6 7
8
9
10 11 12 13 14
15 16 17
18
19
21
20
22
24
26
28
27
29 30 31 32 33
25
23
3. Front Panel Description And Accessing To The Parameters
3.1 Front Panel Description
This LED indicates that a "Warning" alarm was detected
This LED indicates that a "Maintenance" alarm was detected
3
This LCD display is used for displaying the electrical measurements during normal operation,
and editing/inspecting programming parameters in program mode.
This LED indicates that Mains voltage and frequency is within limits and is ready to take over the
load.
This LED shows that the load is supplied from the mains.
This LED shows that the load is supplied from the generator.
8
This LED indicates that Generator voltage and frequency is within limits and is ready to take over
the load.
This LED indicates that the engine has started and is running.
10
11
This LED shows that the unit is in the AUTO mode.
This LED shows that the unit is in the TEST mode.
This LED shows that the unit is in the MANUAL mode.
In the MAN, AUTO and TEST modes, this LED indicates that the engine is starting up or is
running.
This LED shows that the unit is in the STOP mode.
7
