©2020 EMS Ltd. All rights reserved Page 14 of 36 MK349-0001-99 (Issue 1) 22/10/2020 AJM
Re-fit door
Re-connect the ribbon cable and re-fit the door hinges.
Connect backup battery.
230 VAC WZMs only.
+ (RED) PSU lead
- (BLACK) PSU lead
- (BLACK)
battery
connector
+ (RED) battery
connector
1. 3.2. 4.
!
Warning
Observe battery polarity!
