©2020 EMS Ltd. All rights reserved Page 2 of 36 MK349-0001-99 (Issue 1) 22/10/2020 AJM
Contents
Introduction 3
Important notes 3
Additional documentation 4
Overview of system setup 5
What’s in the box 7
WZM features 8
Side cover removal 8
Open WZM 9
Optional door removal 9
Cable entry 10
Fix WZM to wall 10
Addressable fire system wiring
11
Conventional fire system wiring
12
Mains power connections 13
24 VDC power connections 13
Re-fit door 14
Connect backup battery 14
Remove 3V battery tab 15
Apply power 15
Engineer menu entry 16
Set time & date 17
Install devices 18
Add devices to system 19
Device attributes 20
Device location text 22
Text entry 23
Set the panel type 24
Sounder tones 25
Sounder duration 27
Sounder activation method 28
Pulsed output 29
Device indicator operation 31
Device signal levels 32
Test devices 33
Congratulations 36
