EMS SmartCell - Pulsed Output; Configuring Pulsed Output for Relays

©2020 EMS Ltd. All rights reserved Page 29 of 36 MK349-0001-99 (Issue 1) 22/10/2020 AJM
View System Status
Maintenance/Test
Device Options
WZM Settings
Panel Type
Sounder Options
Device Indicator
Default Tone Select
Sounder Duration
Sounder Activation
Pulsed Output
Default Tone Select
Sounder Duration
Sounder Activation
Pulsed Output
From access level 3 (as previously shown
on page 16), press the button until
the screen displays:
Press the button and the screen will
display:
Press the button until the screen will
displays:
Press the button and the screen will
display:
Press the button until the screen will
displays:
Press the button and the screen will
display:
Press the and buttons, until the
screen displays the required relay type:
In this example, the fault relay has been
chosen.
Pulsed output
As default the PULSED OUTPUT for the fire and the fault relays is set to
latched. Upon an activation, the relay will remain latched in alarm until the
WZM is reset. To alternatively pulse into alarm for a pre-defined period of
time (range from 5-60 seconds) before automatically clearing, follow the
steps below.
