Cerabar M, Deltabar M, Deltapilot M Commissioning with an operating menu (onsite display/FieldCare)
Endress+Hauser 119
8.11.2 Measurement
Expert → Measurement
Download select
Display
Selection of data records for the Upload/Download function in Fieldcare.
Prerequisite:
DIP switch 1, 3, 4 and 5 set to "OFF", DIP switch 2 set to "ON" (see picture in
Chap. 6.2.1)).
A download with the factory setting "Copy configuration" causes all parameters
needed for a measurement to be downloaded. If the "Copy configuration" setting is
changed, it takes effect only when a corresponding release code is entered into the
parameter "Operator code/S_W_LOCK".
Options:
• Copy configuration: With this option, general configuration parameters are
overwritten except for serial number, order number, calibration, position
adjustment, application, and tag information.
• Device replacement: With this option, general configuration parameters are
overwritten except for serial number, order number, calibration and position
adjustment.
• Electronics replacement: This option contains all parameters from "Configuration
copy" and "Device replacement" and: "position adjustment", "sensor trimm", "serial
number", "order number".
The control strategy is not affected by a download.
Selection of device replacement or electronics replacement takes effect only if a
corresponding release code has been entered beforehand.
Factory setting:
Copy configuration
Parameter name Description
Lin./SQRT switch (133)
(Deltabar)
Display
Displays the status of DIP switch 4 on the electronic insert, which is used to define
the output characteristics of the device.
Display:
• SW setting
• Square root
The square root signal is used.
Factory setting
SW setting
Measuring mode (005)
Measuring mode (182)
Options
Select the measuring mode.
The operating menu is structured differently depending on the measuring mode
selected.
If the measuring mode is changed, no conversion takes place. If necessary, the
device has to be recalibrated after the measuring mode has been changed.
Options:
• Pressure
•Level
• Flow (Deltabar M only)
Factory setting
Pressure or as per order specifications
