Commissioning with the FF configuration program Cerabar M, Deltabar M, Deltapilot M
172 Endress+Hauser
Write Alarm/
WRITE_ALM
Display
Index: 40
Data type: DS-72
Access: wr for Auto,
OOS
The Write Alarm/WRITE_ALM parameter is a structured parameter consisting of five
elements.
UNACKNOWLEDGED
• If the "Deactivated" option was selected via the Acknowledge Option/ACK_OPTION
parameter for the alarm that occurred, this alarm can only be acknowledged by
means of this element.
ALARM_STATE
• Displays the status of the write protection alarm.
TIME_STATE
• Displays the time when the alarm occurred.
SUB_CODE
• Displays the reason why the alarm was reported.
VALUE
• Displays the value of the corresponding parameter at the time the alarm was
reported.
ITK Version/ITK_VER
Display
Index: 41
Data type: unsigned16
Access: read only
Displays the revision version (major revision number) of the interoperability test kit
(ITK).
Factory setting:
5
Resource Block - Endress+Hauser parameters
Parameter Description
Device dialog/
DEVICE_DIALOG
Display
Index: 42
Data type: unsigned8
Access: read only
If configuration is unsuitable, this parameter displays a message indicating that a
configuration error is present. The message can indicate which parameter was
incorrectly configured.
Operator code/
S_W_LOCK
Entry
Index: 43
Data type: unsigned16
Access: wr for Auto,
OOS
Use this function to enter a code to lock or unlock operation.
Options:
•To lock: Enter a number  the release code.
• To unlock: Enter the release code.
The release code is "0" in the order configuration. Another release code can be defined
in the Code definition/USER_S_W_UNLOCK parameter. If the user has forgotten the
release code, it can be made visible again by entering the number sequence "5864".
Factory setting:
0
Lockstate/
STATUS_LOCKING
Index: 44
Data type: unsigned8
Access: read only
Displays the current locking status of the device or conditions that can lock the device
(hardware locking, software locking).
DIP switch/
SWITCH_STATUS_LIST
Display
Index: 45
Data type: unsigned8
Access: read only
Displays the status of the active DIP switches.
Resource Block - standard parameters
Parameter Description
