Commissioning with an operating menu (onsite display/FieldCare) Cerabar M, Deltabar M, Deltapilot M
124 Endress+Hauser
Empty calib. (028)
Empty calib. (011)
Entry
Enter the output value for the lower calibration point (container empty).
The unit defined in "Unit before lin. (025)" must be used.
• In the case of wet calibration, the level (container empty) must actually be
available. The associated pressure is then automatically recorded by the device.
• In the case of dry calibration, the level (container empty) does not have to be
available. The associated pressure has to be entered in the "Empty pressure
(029)" parameter for the "In pressure" level selection. The associated height has
to be entered in the "Empty height (030)" parameter for the "In height" level
selection.
Factory setting:
0.0
Empty pressure (029)
Empty pressure (185)
Entry/Display
Enter the pressure value for the lower calibration point (container empty).
See also "Empty calib. (028)".
Prerequisite
• "Level selection" = In pressure
• "Calibration mode" = Dry -> entry
• "Calibration mode" = Wet -> display
Factory setting:
0.0
Empty height (030)
Empty height (186)
Entry/Display
Enter the height value for the lower calibration point (container empty). Select the
unit via the "Height unit (026)" parameter.
Prerequisite:
• "Level selection" = "In height"
• "Calibration mode" = Dry -> entry
• "Calibration mode" = Wet -> display
Factory setting:
0.0
Full calib. (031)
Full calib. (012)
Entry
Enter the output value for the upper calibration point (container full).
The unit defined in "Unit before lin. (025)" must be used.
• In the case of wet calibration, the level (container full) must actually be
available. The associated pressure is then automatically recorded by the device.
• In the case of dry calibration, the level (container full) does not have to be
available. The associated pressure has to be entered in the "Full pressure (032)"
parameter for the "In pressure" level selection. The associated height has to be
entered in the "Full height (033)" parameter for the "In height" level selection.
Factory setting:
100.0
Full pressure (032)
Full pressure (187)
Entry/Display
Enter the pressure value for the upper calibration point (container full).
See also "Full calib. (031)".
Prerequisite
• "Level selection" = In pressure
• "Calibration mode" = Dry -> entry
• "Calibration mode" = Wet -> display
Factory setting:
Upper-range limit (URL) of the sensor
Full height (033)
Full height (188)
Entry/Display
Enter the height value for the upper calibration point (container full). Select the
unit via the "Height unit (026)" parameter.
Prerequisite:
• "Level selection" = "In height"
• "Calibration mode" = Dry -> entry
• "Calibration mode" = Wet -> display
Factory setting:
Upper-range limit (URL) is converted to a height unit
Parameter name Description
