Commissioning with an operating menu (onsite display/FieldCare) Cerabar M, Deltabar M, Deltapilot M
130 Endress+Hauser
Expert → Communication → Analog Input 1 to 5
*

Not available for Deltabar M.
Analog Input Parameter name (Display Id) Explanation
1 Channel/CHANNEL (171)
See the following table.
Out value (195)
Out status (196)
2 Channel/CHANNEL (200)
Out value (201)
Out status (202)
3 Channel/CHANNEL (238)
Out value (239)
Out status (240)
4 Channel/CHANNEL (241)
Out value (242)
Out status (243)
5 (Deltabar M) Channel/CHANNEL (255)
Out value (256)
Out status (257)
Parameter name Description
Channel/CHANNEL
Display
The current selected Channel/CHANNEL is displayed for instantiated analog inputs. The following list indicates the possible
channels:
Channel/
CHANNEL
(Set as Default for
pre-instantiated Block)
English text German Text
1
2 *

3
4
5
(AI 1)
(AI 2) Cerabar/Deltapilot
(AI 2) Deltabar
-
-
Primary value
Sensor temperature *

Pressure
Max. pressure
Level before linearization
Totalizer 1
Totalizer 2
Hauptmesswert
Sensortemperatur *

Druck gemessen
Maximaler Druck
Füllstand vor Linearisierung
Summenzähler 1
Summenzähler 2
Out value
Display
The current value is displayed for instantiated analog inputs, along with the individual units.
Out status
Display
The current status is displayed for instantiated analog inputs.
The following list indicates the status and the related text of the AI OUT value:
Status
Bad
Uncertain
Good non-cascaded
Good cascaded
=
=
=
=
Text
BAD
UNCERTAIN
GOOD
GOOD
