Cerabar M, Deltabar M, Deltapilot M Commissioning with the FF configuration program
Endress+Hauser 189


Simulation value
Pressure

Corrected Press.
Damping
Pressure af. damp
Electr. Delta P
Measuring pressure
P
Pressure Level
PV PV = Primary Value

Analog Input Block
Deltabar M
Transducer Block Sensor
Sensor pressure
Sensor trim

Position
adjustment

Corrected Press.
Damping
Pressure af. damp

Measuring pressure
P
Pressure Level Flow

PV PV = Primary Value

Level before lin/
MEASURED_LEVEL_AFTER_
SIMULATION
Display
Index: 56
Data type: float
Access: read only
Displays the level value prior to linearization.
Pressure Transducer Block (Endress+Hauser parameters)
Parameter Description
