Commissioning with the FF configuration program Cerabar M, Deltabar M, Deltapilot M
188 Endress+Hauser
Edit table/
LINEARIZATION_TABLE_EDI
T
Display, selection
Index: 51
Data type: unsigned8
Access: OOS
Select the function for entering the table.
Options:
• Next point: enter the next point.
• Current point: stay on the current point to correct a mistake for example.
• Previous point: skip back to the previous point to correct a mistake for
example.
• Insert point: insert an additional point (see example below).
• Delete point: delete the current point (see example below).
Example: Add a point - in this case between the 4th and 5th point for example
– Select point 5 via the "Line-numb." parameter.
– Select the "Insert point" option via the "Edit table" parameter.
– Point 5 is displayed for the "Line-numb" parameter. Enter new values for the
"X-value" and "Y-value" parameters.
Example: Delete a point - in this case the 5th point for example.
– Select point 5 via the "Line-numb." parameter.
– Select the "Delete point" option via the "Edit table" parameter.
– The 5th point is deleted. All of the subsequent points are moved up one
number i.e. following deletion, the 6th point becomes Point 5.
Factory setting:
Current point
Tank Description/
LEVEL_TANK_
DESCRIPTION
Entry
Index: 52
Data type: visible string
Access: wr for Auto, OOS
Enter tank description. (max. 32 alphanumeric characters)
Factory setting:
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Tank content/
MEASURED_TANK_CONTEN
T_AFTER_SIM
Display
Index: 53
Data type: float
Access: read only
Displays the level value after linearization.
Sensor pressure/
PRESSURE_1_AFTER_SENSO
R
Display
Index: 54
Data type: float
Access: read only
Displays the measured pressure before sensor trim, position adjustment and
damping.  See also the following graphic, Meas. pressure/
PRESSURE_1_FINAL_VALUE parameter description.
Pressure af. damp./
PRESSURE_1_AFTER_DAMPI
NG
Display
Index: 55
Data type: float
Access: read only
Displays the measured pressure after sensor trim, position adjustment and
damping. This value corresponds to the Primary Value/PRIMARY_VALUE
parameter in the "Pressure" measuring mode.
Cerabar M /
Deltapilot M
Sensor
Sensor Pressure
Sensor trim

Position
adjustment
Pressure Transducer Block (Endress+Hauser parameters)
Parameter Description
