Cerabar M, Deltabar M, Deltapilot M Commissioning with the FF configuration program
Endress+Hauser 187
Lin. mode/LINEARIZATION_
TABLE_MODE
Entry
Index: 46
Data type: unsigned8
Access: OOS
Select the linearization mode.
Options:
•Linear
The level is output without being converted beforehand. Level before lin/
MEASURED_LEVEL_AFTER_SIMULATION is output.
• Erase table
The existing linearization table is deleted.
• Manual entry (sets the table to the edit mode, an alarm is output):
The value pairs of the table (X-value:/TB_LINEARIZATION_
TABLE_X_VALUE and Y-value:/TB_LINEARIZATION_ TABLE_Y_VALUE)
are entered manually.
• Semiautomatic entry (sets the table to the edit mode, an alarm is output):
The container is emptied or filled in stages in this entry mode. The device
automatically records the level value (X-value:/TB_LINEARIZATION_
TABLE_X_VALUE). The associated volume, mass or %-value is entered
manually (X-value:/TB_LINEARIZATION_ TABLE_X_VALUE).
•Activate table
The table entered is activated and checked with this option. The device shows
the level after linearization.
Factory setting:
Manual
Unit after lin./
AFTER_LINEARIZATION_UNI
T
Display, selection
Index: 47
Data type: unsigned16
Access: OOS
Select the linearization unit (unit of the Y-value).
Options:
•%
• cm, dm, m, mm
•hl
•in
3
, ft
3
, m
3
•l
•in, ft
•kg, t
•lb
•gal
•Igal
Factory setting:
%
Line numb./LINEARIZATION_
TABLE_INDEX
Entry
Index: 48
Data type: unsigned8
Access: wr for Auto, OOS
Enter the number of the current point in the table.
The subsequent entries in X-value:/TB_LINEARIZATION_ TABLE_X_VALUE
and
Y-value:/TB_LINEARIZATION_ TABLE_Y_VALUE refer to this point.
Input range:
• 1 ... 32
X-value:/
TB_LINEARIZATION_
TABLE_X_VALUE
Display
Index: 49
Data type: float
Access: read only
Display the X-value (level before linearization) for the specific point in the table
and confirm.
Note:
If "Lin. mode" = "Manual", the level value is displayed.
If "Lin. mode" = "Semiautomatic", the level value is displayed and has to be
confirmed by entering the Y-value that cannot be edited.
Prerequisite:
• Lin. mode/LINEARIZATION_ TABLE_MODE = Manual entry.
Y-value:/
TB_LINEARIZATION_
TABLE_Y_VALUE
Entry
Index: 50
Data type: float
Access: OOS
Enter the Y-value (value after linearization) for the specific point in the table in
the "Semiautomatic" mode.
Note:
If "Lin. mode" = "Manual", the system displays the points after linearization.
If "Lin. mode" = "Semiautomatic", entry of the points after linearization.
The linearization table must be monotonic increasing or decreasing.
Pressure Transducer Block (Endress+Hauser parameters)
Parameter Description
