Endress+Hauser Cerabar M - Page 190

Commissioning with the FF configuration program Cerabar M, Deltabar M, Deltapilot M
190 Endress+Hauser
Lin tab index 01/
LIN_TAB_X_Y_VALUE_1
Entry/Display
Index: 57
Data type: record
Access: OOS
Position 1 of the X and Y values of the linearization table.
The X and Y values can be entered (edited) if the Lin. mode/LINEARIZATION_
TABLE_MODE is set to "Manual". The data can only be displayed if the Lin.
mode/LINEARIZATION_ TABLE_MODE is not set to "Manual".
...
...
...
Lin tab index 32/
LIN_TAB_X_Y_VALUE_32
Entry/Display
Index: 88
Data type: record
Access: OOS
Position 32 of the X and Y values of the linearization table.
The X and Y values can be entered (edited) if the Lin. mode/LINEARIZATION_
TABLE_MODE is set to "Manual". The data can only be displayed if the Lin.
mode/LINEARIZATION_ TABLE_MODE is not set to "Manual".
Sensor meas. type/
SENSOR_MEASUREMENT_TY
PE
Display
Index: 89
Data type: unsigned16
Access: read only
Displays the sensor type.
• Deltabar M = differential
• Cerabar M with gauge pressure sensors = gauge
• Cerabar M with absolute pressure sensors = absolute
• Deltapilot M with gauge pressure sensors = gauge
Height unit/
HEIGHT_UNIT_EASY
Options
Index: 90
Data type: unsigned16
Access: OOS
Select the height unit. The measured pressure is converted to the selected
height unit using the Density unit/DENSITY_UNIT_EASY and Adjust density/
LEVEL_ADJUST_DENSITY_EASY parameter.
Prerequisite:
Primary Value Type/PRIMARY_VALUE_TYPE parameter is set to"Level height"
or "Lev. height+LinTab".
Options:
•mm
•m
•in
•ft
Factory setting:
m
Pressure Transducer Block (Endress+Hauser parameters)
Parameter Description
