Cerabar M, Deltabar M, Deltapilot M Commissioning with the FF configuration program
Endress+Hauser 191
Unit before Lin./
OUT_UNIT_EASY
Options
Index: 91
Data type: unsigned16
Access: OOS
Select the unit for the measured value display for the level before linearization.
The unit selected is only used to describe the measured value. This means that
the measured value is not converted when a new output unit is selected.
Example:
• Current measured value: 0.3 ft
• New output unit: m
• New measured value: 0.3 m
Options
•%
• mm, cm, dm, m
•ft, in
•m
3
, in
3
•l, hl
•ft
3
• gal, Igal
•kg, t
•lb
Factory setting:
%
Calibration mode/
LEVEL_ADJUST_MODE_EASY
Options
Index: 92
Data type: unsigned8
Access: OOS
Select the calibration mode.
Options:
•Wet
Wet calibration takes place by filling and emptying the container. In the case
of two different levels, the level, volume, mass or percentage value entered is
assigned to the pressure measured at this point in time. ( See also this
table, Empty calibration/LOW_LEVEL_EASY and Full calib./
HIGH_LEVEL_EASY parameter descriptions)
•Dry
Dry calibration is a theoretical calibration. For this calibration, you specify
two pressure/level value pairs via the following parameters Empty
calibration/LOW_LEVEL_EASY, Empty pressure/
LOW_LEVEL_PRESSURE_EASY, Full calib./HIGH_LEVEL_EASY and Full
pressure/HIGH_LEVEL_PRESSURE_EASY.
Factory setting:
Wet - if PRIMARY_VALUE_TYPE "Level" or "Level+LinTab"
Dry - if PRIMARY_VALUE_TYPE "Level height" or "Lev height+LinTab"
Density unit/
DENSITY_UNIT_EASY
Display
Index: 93
Data type: unsigned16
Access: read only
Displays the density unit. The measured pressure is converted to a height using
the Height unit/HEIGHT_UNIT_EASY and Adjust density/
LEVEL_ADJUST_DENSITY_EASY parameters.
Factory setting:
•g/cm
3
Adjust density/
LEVEL_ADJUST_DENSITY_EA
SY
Index: 94
Data type: FLOAT
Access: OOS
Enter the density of the medium. The measured pressure is converted to a
height using the Height unit/HEIGHT_UNIT_EASY, Density unit/
DENSITY_UNIT_EASY and Adjust density/LEVEL_ADJUST_DENSITY_EASY
parameters.
Factory setting:
1.0
Pressure Transducer Block (Endress+Hauser parameters)
Parameter Description
